WIRE ROPE
Lifting and luffing mechanisms of cranes (such as quay cranes and gantry cranes), tower crane hook groups, and automobile crane winch systems.
Open-pit mine electric shovels and slope winches, drilling rig hoisting systems (such as winches), drill rod hoisting and derrick installation.
Metallurgical blast furnace winches, cable cars and ropeway traction.
Ship loading and unloading systems, deck cranes, cargo net hoisting require corrosion resistance and high strength, and galvanized 6x19 can be used in marine environment engineering.
| Nominal diameter (mm) |
Approx. weight (kg/100m) |
Minimum breaking force (kN) | ||
| 1770 | 1960 | 2160 | ||
| 6 | 13.7 | 21.0 | 23.3 | 25.7 |
| 6.35 | 15.3 | 23.6 | 26.1 | 28.7 |
| 7 | 18.6 | 28.6 | 31.7 | 34.9 |
| 8 | 24.3 | 37.4 | 41.4 | 45.6 |
| 9 | 30.8 | 47.3 | 52.4 | 57.7 |
| 9.53 | 34.5 | 53.0 | 58.7 | 64.7 |
| 10 | 38.0 | 58.4 | 64.7 | 71.3 |
| 11 | 46.0 | 70.7 | 78.3 | 86.2 |
| 12 | 54.7 | 84.1 | 93.1 | 103 |
| 12.7 | 61.3 | 94.2 | 104 | 115 |
| 13 | 64.2 | 98.7 | 109 | 120 |
| 14 | 74.5 | 114 | 127 | 140 |
| 14.3 | 77.7 | 119 | 132 | 146 |
| 15.9 | 96.1 | 148 | 164 | 180 |
| 16 | 97 | 150 | 166 | 182 |
| 18 | 123 | 189 | 210 | 231 |
| 19 | 137 | 211 | 233 | 257 |
| 20 | 152 | 234 | 259 | 285 |
| 22 | 184 | 283 | 313 | 345 |
| 22.2 | 187 | 288 | 319 | 351 |
| 24 | 219 | 336 | 373 | 411 |
| 25.4 | 245 | 377 | 417 | 460 |
| 26 | 257 | 395 | 437 | 482 |
| 28 | 298 | 458 | 507 | 559 |
| 28.6 | 311 | 478 | 529 | 583 |
| 30 | 342 | 526 | 582 | 642 |
| 32 | 389 | 598 | 662 | 730 |
| 36 | 492 | 757 | 838 | 924 |
| 40 | 608 | 935 | 1030 | 1140 |
| 44 | 736 | 1130 | 1250 | 1380 |
| 48 | 876 | 1350 | 1490 | 1640 |
| 52 | 1030 | 1580 | 1750 | 1930 |
| 56 | 1190 | 1830 | 2030 | 2240 |
| 60 | 1370 | 2100 | 2330 | 2570 |
| Nominal diameter (mm) |
Approx. weight (kg/100m) |
Minimum breaking force (kN) | ||
| 1770 | 1960 | 2160 | ||
| 6 | 15.0 | 22.7 | 25.1 | 27.7 |
| 6.35 | 16.9 | 25.4 | 28.1 | 31.0 |
| 7 | 20.5 | 30.9 | 34.2 | 37.7 |
| 8 | 26.8 | 40.3 | 44.7 | 49.2 |
| 9 | 33.9 | 51.0 | 56.5 | 62.3 |
| 9.53 | 38.0 | 57.2 | 63.4 | 69.8 |
| 10 | 41.8 | 63.0 | 69.8 | 76.9 |
| 11 | 50.6 | 76.2 | 84.4 | 93.0 |
| 12 | 60.2 | 90.7 | 100 | 111 |
| 12.7 | 67.4 | 102 | 113 | 124 |
| 13 | 70.6 | 106 | 118 | 130 |
| 14 | 81.9 | 124 | 137 | 151 |
| 14.3 | 85.5 | 129 | 143 | 157 |
| 15.9 | 106 | 159 | 176 | 194 |
| 16 | 107 | 161 | 179 | 197 |
| 18 | 135 | 204 | 226 | 249 |
| 19 | 151 | 227 | 252 | 278 |
| 20 | 167 | 252 | 279 | 308 |
| 22 | 202 | 305 | 338 | 372 |
| 22.2 | 206 | 311 | 344 | 379 |
| 24 | 241 | 363 | 402 | 443 |
| 25.4 | 270 | 407 | 450 | 496 |
| 26 | 283 | 426 | 472 | 520 |
| 28 | 328 | 494 | 547 | 603 |
| 28.6 | 342 | 515 | 571 | 629 |
| 30 | 376 | 567 | 628 | 692 |
| 32 | 428 | 645 | 715 | 787 |
| 34.9 | 509 | 767 | 850 | 937 |
| 36 | 542 | 817 | 904 | 997 |
| 40 | 669 | 1010 | 1120 | 1230 |
| 44 | 809 | 1220 | 1350 | 1490 |
| 48 | 963 | 1450 | 1610 | 1770 |
| 52 | 1130 | 1700 | 1890 | 2080 |
| 56 | 1310 | 1980 | 2190 | 2410 |
| 60 | 1500 | 2270 | 2510 | 2770 |
