WIRE ROPE
Suitable for occasions where fixed structures or equipment are required and the bending load is small, such as stable cables for construction sites and tower cranes.
Used for static or low-frequency moving load-bearing and traction operations, such as equipment hauling and cargo fixing rigging.
Suitable for making slings or binding ropes with stable force direction and small bending amplitude, commonly used in simple lifting scenarios.
Used as auxiliary traction ropes in some construction machinery (such as winches and cable cars), especially suitable for environments with light wear and no frequent bending.
Nominal diameter (mm) |
Approx. weight (kg/100m) |
Minimum breaking force (kN) | ||
1570 | 1770 | 1960 | ||
3 | 3.16 | 4.34 | 4.89 | 5.42 |
4 | 5.62 | 7.71 | 8.69 | 9.63 |
5 | 8.78 | 12.0 | 13.6 | 15.0 |
6 | 12.6 | 17.4 | 19.6 | 21.7 |
7 | 17.2 | 23.6 | 26.6 | 29.5 |
8 | 22.5 | 30.8 | 34.8 | 38.5 |
9 | 28.4 | 39.0 | 44.0 | 48.7 |
10 | 35.1 | 48.2 | 54.3 | 60.2 |
11 | 42.5 | 58.3 | 65.8 | 72.8 |
12 | 50.5 | 69.4 | 78.2 | 86.6 |
13 | 59.3 | 81.5 | 91.8 | 102 |
14 | 68.8 | 94.5 | 107 | 118 |
16 | 89.9 | 123 | 139 | 154 |
18 | 114 | 156 | 176 | 195 |
20 | 140 | 193 | 217 | 241 |
22 | 170 | 233 | 263 | 291 |
24 | 202 | 278 | 313 | 347 |
26 | 237 | 326 | 367 | 407 |
28 | 275 | 378 | 426 | 472 |
Nominal diameter (mm) |
Approx. weight (kg/100m) |
Minimum breaking force (kN) | ||
1570 | 1770 | 1960 | ||
3 | 3.43 | 5.12 | 5.77 | 6.39 |
4 | 6.10 | 9.09 | 10.3 | 11.4 |
5 | 9.53 | 14.2 | 16.0 | 17.7 |
6 | 13.7 | 20.5 | 23.1 | 25.5 |
7 | 18.7 | 27.8 | 31.4 | 34.8 |
Nominal diameter (mm) |
Approx. weight (kg/100m) |
Minimum breaking force (kN) | ||
1570 | 1770 | 1960 | ||
8 | 25.6 | 33.4 | 37.6 | 41.6 |
9 | 32.4 | 42.2 | 47.6 | 52.7 |
10 | 40.0 | 52.1 | 58.8 | 65.1 |
11 | 48.4 | 63.1 | 71.1 | 78.7 |
12 | 57.6 | 75.1 | 84.6 | 93.7 |
13 | 67.6 | 88.1 | 99.3 | 110 |
14 | 78.4 | 102 | 115 | 128 |
15.9 | 101.1 | 132 | 149 | 165 |
16 | 102 | 133 | 150 | 167 |
18 | 130 | 169 | 190 | 211 |
20 | 160 | 208 | 235 | 260 |
22 | 194 | 252 | 284 | 315 |
24 | 230 | 300 | 338 | 375 |
26 | 270 | 352 | 397 | 440 |
28 | 314 | 409 | 461 | 510 |
