WIRE ROPE
Designed for suspended platform, zinc-coated.
| Nominal diameter (mm) |
Approx. weight (kg/100m) |
Minimum breaking force (kN) | ||
| 1570 | 1770 | 1960 | ||
| 6 | 14.8 | 20.3 | 22.9 | 25.4 |
| 7 | 20.1 | 27.7 | 31.2 | 34.6 |
| 8 | 26.2 | 36.2 | 40.8 | 45.2 |
| 8.3 | 28.2 | 38.9 | 43.9 | 48.6 |
| 8.6 | 30.3 | 41.8 | 47.1 | 52.2 |
| 9 | 33.2 | 45.8 | 51.6 | 57.2 |
| 9.1 | 34.0 | 46.8 | 52.8 | 58.4 |
| 9.5 | 37.0 | 51.0 | 57.5 | 63.7 |
| 10 | 41.0 | 56.5 | 63.7 | 70.6 |
| 11 | 49.6 | 68.4 | 77.1 | 85.4 |
| 12 | 59.0 | 81.4 | 91.8 | 102 |
| 13 | 69.3 | 95.5 | 108 | 119 |
| 14 | 80.4 | 111 | 125 | 138 |
| 16 | 105 | 145 | 163 | 181 |
| 18 | 133 | 183 | 206 | 229 |
| 20 | 164 | 226 | 255 | 282 |
| 22 | 198 | 274 | 308 | 342 |
| 24 | 236 | 326 | 367 | 406 |
| 26 | 277 | 382 | 431 | 477 |
| 28 | 321 | 443 | 500 | 553 |
