zinc-coated steel strand is widely used in the power and construction industries. It is made of galvanized steel wire stranded together and has become a key material due to its high strength and corrosion resistance.

Features

High Strength: Tensile strength reaches 1270-1670MPa, capable of withstanding enormous tensile forces.
Corrosion Resistance: The galvanized coating provides long-term protection, adapting to harsh environments.
Stability: Structural design ensures no deformation during long-term use.

Applications

Power Engineering: Used for overhead guy wires, ground wires for transmission lines, etc.
Building Structures: Used as load-bearing cables or structural cables to enhance building stability.
Other Applications: Highway guardrails, bridge cables, etc.

DIA. strand	DIA. wire	Approx. length mass	Common Grade	Siemens- Martin Grade	High- Strength Grade	Extra High- Strength Grade
mm	mm²	kg/1000m	kN	kN	kN	kN
12.70	2.54	751.0	33.895	56.492	84.961	118.768
14.29	2.87	949.0	42.881	71.616	107.202	149.905
15.88	3.18	1186.0	48.930	80.513	124.995	178.819
19.05	3.81	1721.0	71.172	116.543	181.487	259.331
22.22	4.50	2356.0	97.416	159.691	248.211	354.523
25.40	5.08	3089.0	127.664	209.066	325.610	464.839

Minimum mass of zinc

DIA. Wire	Class 1	Class A	Class B	Class C
mm	g/m²	g/m²	g/m²	g/m²
1.04	46	122	244	366
1.32	46	122	244	366
1.57	46	153	305	458
1.65	46	153	305	458
1.83	46	153	305	458
2.03	92	183	366	549
2.36	92	214	427	641
2.54	92	214	427	641
2.64	92	244	488	732
2.77	92	244	488	732
2.87	92	244	488	732
3.05	92	259	519	778
3.18	92	259	519	778
3.30	92	259	519	778
3.63	122	275	549	824
3.68	122	275	549	824
3.81	122	275	549	824
4.09	122	275	549	824
4.19	122	275	549	824
4.50	122	275	549	824
4.55	122	275	549	824
4.78	122	305	610	915
5.08	122	305	610	915
5.26	122	305	610	915
