Truck crane, tower crane, vehicle crane, crawler crane, etc.
| Nominal diameter (mm) |
Approx. weight (kg/100m) |
Minimum breaking force (kN) | ||
| 1570 | 1770 | 1960 | ||
| 10 | 41.0 | 56.5 | 63.7 | 70.6 |
| 11 | 49.6 | 68.4 | 77.1 | 85.4 |
| 12 | 59.0 | 81.4 | 91.8 | 102 |
| 13 | 69.3 | 95.5 | 108 | 119 |
| 14 | 80.4 | 111 | 125 | 138 |
| 16 | 105 | 145 | 163 | 181 |
| 18 | 133 | 183 | 206 | 229 |
| 20 | 164 | 226 | 255 | 282 |
| 22 | 198 | 274 | 308 | 342 |
| 24 | 236 | 326 | 367 | 406 |
| 26 | 277 | 382 | 431 | 477 |
| 28 | 321 | 443 | 500 | 553 |
| 30 | 369 | 509 | 573 | 635 |
| 32 | 420 | 579 | 652 | 723 |
| 34 | 474 | 653 | 737 | 816 |
| 36 | 531 | 732 | 826 | 914 |
| 38 | 592 | 816 | 920 | 1020 |
| 40 | 656 | 904 | 1020 | 1130 |
