Used for tugboat towing, cargo net fixing and floating timber bundling, suitable for bundling and fixing of large equipment during transportation (such as port machinery loading and bundling) and mooring of cargo yards. quality B zinc-coated is necessary.
Minimum breaking force in the below table refers to ISO 2408.
We do OEM work for Korea brand Youngwire and DSR. Produce wire strands for European brand Gustav wolf and Pheifer.
Reliable quality, great value.
| Nominal diameter (mm) |
Approx. weight (kg/100m) |
Minimum breaking force (kN) | |
| 1570 | 1770 | ||
| 8 | 20.4 | 28.7 | 32.4 |
| 9 | 25.8 | 36.4 | 41.0 |
| 10 | 31.8 | 44.9 | 50.6 |
| 11 | 38.5 | 54.3 | 61.3 |
| 12 | 45.8 | 64.7 | 72.9 |
| 13 | 53.7 | 75.9 | 85.6 |
| 14 | 62.3 | 88.0 | 99.2 |
| 16 | 81.4 | 115 | 130 |
| 18 | 103 | 145 | 164 |
| 20 | 127 | 180 | 202 |
| 22 | 154 | 217 | 245 |
| 24 | 183 | 259 | 292 |
| 26 | 215 | 304 | 342 |
| 28 | 249 | 352 | 397 |
| 30 | 286 | 404 | 456 |
| 32 | 326 | 460 | 518 |
| 36 | 412 | 582 | 656 |
| 40 | 509 | 718 | 810 |
